Feature
Space saving designProvide narrow solution for high density application High performance and reliability
Save installation time and labor
Next generation network proof
Parameters
| MTP Type | SM Ferrule | SM Low-Loss Ferrule | MM Ferrule | MM Low-Loss Ferrule |
| Insertion Loss Max(dB) | 0.35 | 0.20 | 0.35 | 0.20 |
| Insertion Maximum(dB) | 0.70 | 0.35 | 0.60 | 0.35 |
| Return Loss(dB) | PC≥50, UPC≥55, APC≥65 | N/A | ||
| Male/Female | Male: With Pins Female: Without Pins | |||
| Repeatability(dB) | ≤0.2 (500 times) | |||
| Operating Temperature | -40~+85 | |||
| Optical Performance | ¡¡ | ¡¡ | ¡¡ | ¡¡ |
| Insertion Loss Max(dB) | 0.25 | 0.15 | 0.25 | 0.15 |
| Return Loss(dB) | 55/65 | 55/65 | N/A | N/A |
Application
Data centerStorage area network
Infiniband
Optical switch and router
Emerging 40Gbps and 100Gbps protocols
Download Product Introduction
