High Performance Patchcord

Product Categories: Patchcords

Product advantages:

High performance patchcords are a range of "best in class" singlemode patchcords employing highest grade components, manufacturing processes and test methods that offer excellent performance for demanding telecommunications and data center applications. High performance patchcords are used where low loss budgets are essential and mayb be considered for splice replacement.

PDF Download:

Product Details

High performance patchcords are a range of "best in class" singlemode patchcords employing highest grade components, manufacturing processes and test methods that offer excellent performance for demanding telecommunications and data center applications. High performance patchcords are used where low loss budgets are essential and mayb be considered for splice replacement.

Feature

Low insertion loss

Good repeatability

High return loss

Mutual insert performance

Good temperature stability

Tensile strength

Parameters

Specification Parameter
Insertion Loss(dB) ≤0.15
Return Loss(dB) PC≥50, UPC≥55, APC≥65
Repeatability(dB) ≤0.2 (1000 times)
Operating Temperature -40~+85

Application

LAN/WAN

CATV

FTTH

Telecommunication system

Data transmission

High bandwidth 40G & 100G network
